36
Optional accessories
Work bench -
Two tier galvanised
steel work bench
(freestanding) –
1638mm long x 838mm
high x 394mm deep.
Shelf
– Two tier
galvanised steel shelf
(attaches to side panel
of shed) – 1752mm
long x 203mm deep.
Wooden floors
–
High quality exterior grade wooden floors are available
for all models, they are supplied with metal floor
supports.
Stainless Steel Hasp and
staple supplied as standard.
Door location: in 6’ side for all
Apex models and in short side in
all Pent models.
Siting
There are various ways that our Titan sheds can be sited,
concrete bases or paving slabs are both options. For
more alternatives and illustrations please see our website.
Roof style
All sheds prefixed “AP” are Apex roof style and those
prefixed “PP” are Pent roof style.
Pent
Apex
Length
Width
Height
Door
Hard
to apex
width
base area
AP640
(approx 6’x4’)
1314mm 1760mm 2085mm *685mm 1900 x 1455mm
AP660
(approx 6’x6’)
1757mm 1760mm 2085mm *685mm 1900 x 1900mm
AP680
(approx 6’x8’)
2372mm 1760mm 2085mm *685mm 1900 x 2515mm
PP640
(approx 6’x4’)
1760mm 1310mm 2100mm 1160mm 1450 x 1900mm
PP650
(approx 6’x5’)
1760mm 1540mm 2100mm 1395mm 1680 x 1900mm
PP660
(approx 6’x6’)
1760mm 1760mm 2100mm 1395mm 1900 x 1900mm
The door height on all models is 1740mm
*With double door option width is 1395mm
Note:
The above sizes are internal – allow 150mm extra for
external
length
and width measurements.
Premium Range size chart (metric)
Metal Sheds – Technical information
Length
Width
Height
Door
Hard
to apex
width
base area
AP640
(approx 6’x4’)
52”
69”
82”
27”
75” x 57”
AP660
(approx 6’x6’)
70”
69”
82”
27”
75” x 75”
AP680
(approx 6’x8’)
93”
69”
82”
27”
75” x 99”
PP640
(approx 6’x4’)
69”
52”
83”
46”
57” x 75”
PP650
(approx 6’x5’)
69”
61”
83”
55”
66” x 75”
PP660
(approx 6’x6’)
69”
69”
83”
55”
75” x 75”
Premium Range size chart (imperial)
AP680 - Apex roof style
For optimal security a key operated
locking mechanism bolts both top and
base of the door. This is complemented
by a secondary stainless steel hasp and
staple which also serves as an excellent
visible deterrent.
The new Professional range offers
the ultimate in all-round strength and
protection, an excellent package at an
affordable price.
