12
Optional accessories
Windows
The Titan 108 is supplied with two windows as standard
which are fitted both sides of the doors. As an option
this shed can have an additional two windows fitted to
the rear of the shed (giving a maximum of four windows)
or, for security, no windows at all.
The Titan Pent roof models (940, 950, 960) have no
windows. The Titan Apex sheds (630, 640, 660 and 680)
come with one window as standard which can be fitted
either side of the door. As an option these sheds can
have an additional window (so there is a window each
side of the door) or, for security, no windows at all. If
you choose double doors as an option you cannot
have any windows fitted.
Shelving & benching
Two-tier shelving and benching
are available for all Titan models.
The shelving is fixed to the
shed frame and the benching is
freestanding. Shelving dimensions
(two-tier): 69” (1752mm) long
x 8” (203mm) deep. Benching
dimensions (two-tier): 33”
(838mm) high x 15.5” (394mm)
deep with length depending on Titan model from: 43”
(1092mm) to 86” (2184mm)
Wooden floor
High quality wooden floors are available for all models and
are supplied with metal floor supports.
Hasp & padlock
(Pent roof models only)
These quality hasps and padlocks are constructed
from stainless steel and brass for long life, and can
be incorporated onto all Pent roof buildings for even
greater security. They secure both doors and are an
extra visible deterrent to thieves or vandals, especially
if your building is used to store
more expensive items, such
as motorbikes or bicycles (see
photograph). The hasp is used
in addition to our normal keyed
bolting mechanism, which is
standard throughout the range.
Alarm
Key pad operated infra-red movement sensing alarm with
loud (130db) siren comes complete with unique fixing
bracket for easy installation.
Note:
Batteries not included.
Siting
There are various ways that our Titan sheds can be sited,
concrete bases or paving slabs are both options. For
more alternatives and illustrations please see our website.
Roof style
The 940, 950 and 960
are Pent roof style –
all others are Apex.
Pent
Apex
Length
Width
Height
Door
Hard
to apex
width
base area
630
(approx 6’x3’)
1014mm 1760mm 2085mm *685mm 1900 x 1155mm
640
(approx 6’x4’)
1314mm 1760mm 2085mm *685mm 1900 x 1455mm
660
(approx 6’x6’)
1757mm 1760mm 2085mm *685mm 1900 x 1900mm
680
(approx 6’x8’)
2372mm 1760mm 2085mm *685mm 1900 x 2515mm
940
(approx 9’x4’)
2625mm 1310mm 2100mm 1160mm 1450 x 2765mm
950
(approx 9’x5’)
2625mm 1540mm 2100mm 1395mm 1680 x 2765mm
960
(approx 9’x6’)
2625mm 1760mm 2100mm 1395mm 1900 x 2765mm
108
(approx 10’x8’)
2372mm 2980mm 2220mm 1395mm 3175 x 2535mm
The door height on all models is 1740mm
*With double door option width is 1395mm (4’7”)
Titan size chart (metric)
Titan 680 – Apex roof
Metal Sheds – Technical information
Length
Width
Height
Door
Hard
to apex
width
base area
630
(approx 6’x3’)
3’4”
5’9”
6’10”
*2’3”
6’2” x 3’9”
640
(approx 6’x4’)
4’4”
5’9”
6’10”
*2’3”
6’2” x 4’9”
660
(approx 6’x6’)
5’9”
5’9”
6’10”
*2’3”
6’2” x 6’2”
680
(approx 6’x8’)
7’9”
5’9”
6’10”
*2’3”
6’2” x 8’3”
940
(approx 9’x4’)
8’7”
4’4”
6’11”
3’9”
4’9” x 9’1”
950
(approx 9’x5’)
8’7”
5’1”
6’11”
4’7”
5’6” x 9’1”
960
(approx 9’x6’)
8’7”
5’9”
6’11”
4’7”
6’2” x 9’1”
108
(approx 10’x8’)
7’9”
9’9”
7’3”
4’7”
10’5” x 8’4”
Titan size chart (imperial)
Red/White
Anthracite/
White
Blue/White
Olive/
Moorland
Olive
Note:
The above sizes are internal – allow 150mm extra for
external
length
and width measurements.
Colour options: 630, 640, 940, 950 and 960 – choice of either all Olive green
or Two tone Olive / moorland green; 660 and 680 – any of the colours listed
below, 108 – two tone moorland / olive green only.
Bench
Shelf
